Coal Feeding Equipment Feeder Belt Conveyor Low Energy Consumption

Product Description

Belt feeder is a coal feeding equipment developed by our factory for the coal mine industry. After the transformation of our factory, it runs steadily, has fast speed, low noise, and good explosion-proof performance. It is an environmentally friendly product with high efficiency, energy saving, low cost, and large supply. The amount of material can reach thousands of tons per hour, which is unmatched by ordinary models. It is an indispensable equipment in the clean coal production line.
The belt feeder can be widely used in bulk material transportation systems in coal, metallurgy, construction, chemical industry and other industries. It adopts the principle of belt conveyor. The transmission power is a combined stepless speed reducer motor. Its belt speed can be adjusted arbitrarily by manual or frequency converter as needed.

Main Parameters

Product Structure

The connecting section is installed at the mouth of the silo, and a material guide groove is installed below it, and a belt feeding device is installed under the material guide groove; the belt feeding device is composed of a driving roller, a buffer roller and a bracket, a redirecting roller, and a belt , Belt, tensioning device and other parts; the driving device is composed of a motor and an infinitely variable speed reducer, and drives the driving roller through a chain drive; the driving device and the belt feeding device are both installed on the base frame and can be adjusted in position; A maintenance gate mechanism is installed on the upper part of the material guide trough to realize the opening and closing of the feeding port during maintenance and inspection.

Main Features

1. The equipment runs stably and reliably, with low operating power and low energy consumption, but the feeding amount is relatively large, which can reach several thousand tons per hour on average, with high efficiency and stability, and good economic performance.
2. The noise produced by the belt feeder is relatively small, the material is fed in the sealing device, and the input cost is low. It is an energy-saving and environmentally friendly equipment.
3. When adjusting the speed of the equipment, manual or electrical stepless speed regulation can be used. According to different requirements of customers, the feeding amount and running speed can be adjusted to realize remote control operation in an all-round way.
4. The equipment is a very versatile and extremely strong equipment. The universal parts account for more than 90%. It is easy to install and maintain. The wear of each accessory is small and the amount of maintenance is small.
5. The bottom of the silo is provided with multiple sets of buffer rollers, which enhances the impact resistance, effectively protects the belt from wear, and has a long service life.

Field Usage

Henan Green Eco-Equipment Co., Ltd was founded at Xinxiang city, Henan province in 2017, the registered capital is 10 million CNY. We are a professional manufacturer of bulk material conveying equipment in China. Now our main products include belt conveyor, drag conveyor, screw conveyor, bucket elevator, apron feeder, vibrating screen, trommel screen and related spare parts. We supplied a lot of bucket elevators and conveyors to our customers in cement plant, power plant, mine and other industry in the world.

We always believe that product quality is the life of the enterprise, she is the source of continuous development and growth of the enterprise, the quality is the first, the quality is the most important, the quality is the life.

After everyone's unremitting efforts and good supports by customers, now we have:

1. Three factories, and workshops are over eight thousand square meters. We have processing equipment as below: 500 tons heavy duty press machine, Milling machine, plasma cutting machine, wire cutting machine, two meters lathe, plate shearing machine, bending machine, drilling machine , polishing machine and welding machine.

2. We have two senior engineers and eight technicists in conveying fields.

3. More than 80 workers in our factories.

4. Supplied our conveyors to 50+ countries.

5. Annual value of production is more than 5 millions US dollar.
